Wood Walls

Derako® Veneered Grill Wall

The grill elements for ceilings and walls are an ideal acoustic solution with natural charm. The flexibility of the product range ensures complete design freedom for the architect.

Veneered Wood Panels and Tiles are an environmentally friendly building product with endless possibilities. The wood is used efficiently in the production of veneer, as modern production methods ensure that around 800-1000 m2 of veneer can be produced from 1 m3 of wood. With demountable clips, the wall panels can be easily installed or removed.
The core of the panel consists of MDF engineered solid wood (ESW) with a decorative top layer of a high quality natural wood veneer. The dimensional stability of ESW ensures that there is plenty of variety in the widths of the slats.

Key features
  • Variety of organic or engineered wood veneers
  • Different slat width, height and gap can be chosen for design flexibility
  • Additional acoustical wool possible to increase sound absorption
  • Easy and fast installation with special clips
  • Available as a ceiling and wall solution
Performance profile
  • Sound absorption (αw) Up to 0.35
  • Sustainability FSC®, PEFC
  • Reaction to fire B-s2,d0
  • Ceiling / Wall Both versions available

Colours & Veneers

Birch

Spruce

Unsteamed Beech

Steamed Beech

Sycamore

American Cherry

Ash

Basswood

Hemlock

Maple

Gaboon

Zebrano

Bamboo Natural

Pine

Oak

Pear

Walnut

Yellow Poplar

Ayous

Red Oak

Bamboo Caramel

Teak

Sapeli Mahogany

Birch

Spruce

Unsteamed Beech

Steamed Beech

Sycamore

American Cherry

Ash

Basswood

Hemlock

Maple

Gaboon

Zebrano

Bamboo Natural

Pine

Oak

Pear

Walnut

Yellow Poplar

Ayous

Red Oak

Bamboo Caramel

Teak

Sapeli Mahogany

The veneer sheets, with a width of 10-25 cm, are book-matched and glued to form panels. Upon request it is also possible to slip-match or miss-match sheets. See colour card for more information. Colours on screen may vary from the original.

Colours and tones

Technical Details

The slats are pre-assembled as grill elements and connected with a metal dowel or wooden backer. The grill element is simple to install on a wood frame for wall applications. The gap can be any size, but a common rule of thumb is that the gap between the slats does not exceed the slat height. Other slat dimensions are available upon request.
Grill element length: standard 2400 mm
Grill element width: varies between 300 to 500 mm

  • Material MDF engineered solid wood
  • Panel dimensions Slat height: 50 – 150 mm
  • Slat width: 17, 25, 31, 39 mm
  • Panel lengths Slat length: standard 2396 mm
  • Standard modules Various gaps / spacings possible
  • VOC emission class A

Downloads

Brochures
Name Downloads
Product Flyer
Technical Data
Name Downloads
Technical Leaflet | Backer
Technical Leaflet | Dowel
Colour overview
Name Downloads
Colour Card Derako® Veneered Wood
General
Name Downloads
Product Guide
Acoustic Test Results
